Seamless Black Steel Pipe Schedule 40

What is seamless black steel pipe?

Seamless black steel pipe is made up of steel that has not being galvanized. Its name comes from the skin, dark-colored iron oxide coating on its surface. It is used in applications that does not requires galvanized steels.

Black steel pipe's strength makes it ideal for transporting water and gas in rural and urban areas and for conduits that protect electrical wiring and for delivering high pressure steam and air. The oil and petroleum industries use black steel pipe for moving large quantities of oil through remote areas. This is beneficial, since black steel pipe requires very little maintenance. Other uses for black steel pipes include gas distribution inside and outside homes, water wells and sewage systems.

What is a Pipe Schedule?
A pipe schedule (SCH) is a measure of a steel pipe’s nominal wall thickness.

In the past, metal fabricators used three pipe dimensions — standard, extra strong, and double extra strong. Just having these three undetermined dimensions wasn’t helpful, though. So today, steel pipes come in 14 different schedules.

The most commonly used one is schedule 40.

Seamless black steel pipe schedule 40:

Nominal size  [inches]	Outside diameter  [inches]	Outside diameter [mm]	Wall thickness  [inches]	Wall thickness  [mm]	Weight  [lb/ft]	Weight  [kg/m]
1/8	0.405	10.3	0.068	1.73	0.24	0.37
1/4	0.540	13.7	0.088	2.24	0.42	0.84
1/2	0.840	21.3	0.109	2.77	0.85	1.27
3/4	1.050	26.7	0.113	2.87	1.13	1.69
1	1.315	33.4	0.133	3.38	1.68	2.50
1 1/4	1.660	42.2	0.140	3.56	2.27	3.39
1 1/2	1.900	48.3	0.145	3.68	2.72	4.05
2	2.375	60.3	0.154	3.91	3.65	5.44
2 1/2	2.875	73.0	0.203	5.16	5.79	8.63
3	3.500	88.9	0.216	5.49	7.58	11.29
3 1/2	4.000	101.6	0.226	5.74	9.11	13.57
4	4.500	114.3	0.237	6.02	10.79	16.07
5	5.563	141.3	0.258	6.55	14.62	21.77
6	6.625	168.3	0.280	7.11	18.97	28.26
8	8.625	219.1	0.322	8.18	28.55	42.55
10	10.750	273.0	0.365	9.27	40.48	60.31
12	12.750	323.8	0.406	10.31	53.52	79.73
14	14	355.6	0.375	11.13	54.57	94.55
16	16	406.4	0.500	12.70	82.77	123.30
18	18	457.0	0.562	14.27	104.67	155.80
20	20	508.0	0.594	15.09	123.11	183.42
24	24	610.0	0.688	17.48	171.29	255.41
32	32	813.0	0.688	17.48	230.08	342.91

Application of Seamless black steel pipe schedule 40:

1. Low and middle pressure fluid pipeline
2. Casing Pipe
3. Boiler Tube

4. Petroleum and natural gas industry
5. Chemistry industry
6. Electric industry

Can I use black steel pipe for water?

Black steel pipes are never used for transporting potable water.Black steel pipe is used to transport water and natural gas from their sources to homes and businesses. Black pipe is also used for fire sprinkler systems because of its strong resistance to heat.Black steel pipe is not suitable for carrying drinking water because it rusts easily.

Black Pipe Schedule 40 || Black Steel Pipe also known as "straight seam" is most often used in the construction industry for structural or load-bearing purposes above the ground.it is also used in other industries such as trucking, shipping and farm equipment.

Go here if you are looking for "Carbon Steel Black Pipe vs Carbon Steel Galvanized Pipe"
